Specifications
Laser Type:
Semiconductor laser
Wavelength:
980nm/940nm±10nm
Output power:
0.1W-10W
Operation mode:
CW, Single, Repeat
Pulse width:
1ms-1000ms or continuous
Application / Light delivery system:
Core Size (Use only approved systems)≥200µm
Numerical Aperture:
NA = 0.22 – 0.48
Fiber Connector:
SMA 905
Aiming Beam:
Diode laser of 650nm±10nm, 4mW (max), adjustable brightness.
Laser Class:
4
Operation interface:
Color LCD touch screen
Power Supply :
Model: WDY-15007000
input: 100-240Vac 47-63HZ 2.0A
output: 15V 7A
Cooling:
Air cooling
Safety classification:
ClassⅠType B
Dimensions：
265 mm x 200 mm x 210 mm (HxWxD)
Weight :
3 kg
Operating Temperature:
10℃～40℃（In order to better heat dissipation, it is recommended to use temperature of 10-35 ℃）
Storage/Transport Temperature:
-10℃ to +50℃
Humidity Storage/Transport : 10% – 80%,
Operating: 30% – 60%
Waterproof level:
IPX1
Footswitch Waterproof level:
IPX8
